Sentry Mandible

SKU:

Expected Delivery:
Ops-Core Customer Service will contact you in 5-7 business days with expected shipment dates - as all orders require manual verification.

Note: System Platforms (Helmets) currently ship in 6-8 weeks while all other items currently ship in 5-7 business days.

Please contact Ops-Core Customer Service at 617.670.3547 if expedited delivery is required.

Click to view the Purchasing Requirements and Export Compliance Notice related to this product.

$791.00 U.S. Pricing Only
Share
  • Features & Specifications
    • Designed for Ops-Core Sentry XP and LE Mid-Cut Helmets.

    • Provides additional face protection from ballistic and blunt impact.

    • Pair with an Ops-Core Sentry Visor for complete eye and face protection.

    • Unique patented hinge front system provides natural ventilation, which greatly reduces lens fogging, while increasing user comfort.

    • A seamless connection to the Sentry ARC Rail System leaves space for mission critical accessories and components such as cameras, illumination, and other adapters.

    • Folds in half for compact storage and less displacement in a ruck sack or back pack.

    • Tool-less installation and fit to the helmet is easy via the connecting straps that can be adjusted to ensure proper fit and function.

    • Can be donned and doffed with one gloved hand.

    • Designed with Low-Reflective and Low Infra-Red (IR) signature characteristics.

    • Available in Urban Tan, Foliage Green, and Black.



    Testing Protocols and Design:

    • Designed and tested in accordance with Gentex PRS-1000 Product Specification for the Ops-Core Sentry Ballistic Mandible.

    • Meets Blunt Impact Protection to a Modified and Abbreviated U.S. Army Purchase Description Helmet, Advanced Combat (ACH) CO/PD-05-04: 30 October 2007. (Blunt Impact Protection is measured with two impacts in the front center portion of the mandible at 5 Feet Per Second on a Hemispheric Anvil with no impact measuring over 150 G of force tested in ambient, hot and cold conditions.)

    • Environmental affects testing: seawater resistant; weatherometer (accelerated aging); high temperature operating and storage; cold temperature operating and storage; field agent resistant (DEET insect repellant, gasoline, motor oil, petroleum based hydraulic fluid, fire resistant hydraulic fluid, diesel fuel oil, aviation turbine fuel, rifle bore cleaning compound, weapons lubricating oil, and face paint).

    • Ballistic mandible tested against the 9mm 124gr FMJ RN at 1400 fps (+/- 50 fps) Resistance to Penetration (RtP) protocol tested in ambient, hot and cold conditions; and the 17 grain (1.1 gram) Fragment Simulated Projectile (FSP) using a baseline testing method to establish a minimum V-50 of 1850 feet per second (fps) / 564 meters per second (m/s). (V-50 is defined as the velocity of a designated projectile where 50% of the threat will penetrate and 50% will be stopped.)



    Characteristics:

    • Ballistic resistant pucks used in the mandible are a hybrid design of uni-directional polyethylene and aramid materials.

    • Mandible frame is constructed from high impact injected molded plastic.



    Coverage and Weight:

    Size

    Coverage

    Weight

    Medium

    56 in2 (361 cm2)

    1.11 lbs (505 grams)

    Large

    56 in2 (361 cm2)

    1.11 lbs (505 grams)

    X-Large

    62 in2 (400 cm2)

    1.20 lbs (545 grams)

    XX-Large

    62 in2 (400 cm2)

    1.22 lbs (555 grams)



    Click to download the English version of the Product Sell Sheet.
